Castables for ladle working layer is made from high purity corundum, magnesium aluminate spinel and fused MgO as main aggregates, superfine powder bonding technology and appropriate additives.
Castables for ladle working layer is made from high purity corundum, magnesium aluminate spinel and fused MgO as main aggregates, superfine powder bonding technology and appropriate additives.
Advantages of Castables for ladle working layer:
Castables for ladle working layer is featured with good placement properties, high strength, better volume stability, better corrosion and abrasion resistance and thermal shock resistance. In case of re-lining technique is applied, the life of ladle lining can be further prolonged and refractory consumption per ton steel produced can be further reduced, which is proven to be an effective way for low specific refractory consumption and resource saving.
Applications of Castables for ladle working layer:
●Working layer and bottom and Slag line of small
●Bottom and working layer of large-and medium-capacity ladle
|
Product Code |
CH-GBJ88 |
CH-GBJ85 |
CH-GBJ80 |
CH-GBJ75 |
|
Al2O3/% |
≧88 |
≧85 |
≧80 |
≧75 |
|
MgO/% |
3~10 |
3~10 |
5~15 |
6~18 |
|
Bulk density/ g.cm3 |
≧3.05 |
≧3.00 |
≧2.90 |
≧2.80 |
|
Cold Crushing Strength/MPa
|
≧40 (110℃,24h) |
≧40 (110℃,24h) |
≧35 (110℃,24h) |
≧35 (110℃,24h) |
|
≧65 (1550℃,3h) |
≧65 (1550℃,3h) |
≧60 (1550℃,3h) |
≧60 (1550℃,3h) |
|
|
Permanent Linear Change/%
|
0~+1.0 (1550℃,3h) |
0~+1.0 (1550℃,3h) |
0~+1.0 (1550℃,3h) |
0~+1.0 (1550℃,3h) |
|
Application |
Bottom and working layer of large-and medium-capacity ladle |
Working layer and bottom and Slag line of small capacity ladle |
||
The appropriative fireproof castable for kiln door is a high-performance castable developed according to the working conditions of the rotary kiln. Appropriative refractory castable for kiln door has good performance of volume stability, high strength, good wear resistance, thermal shock resistance, corrosion resistance，anti-stripping when using.
The alkali-resistant firebricks use silica, coke stones and appropriate additives to improve the microstructure of the product.
Monolithic castables for ladle safety lining are composed of corundum, high quality bauxite, superfine powder and other ingredients and featured with good work ability on site casting, high strength, high volume stability and long life span.
