Castable for carbon calcined rotary kiln has the advantages of high strength, high wear resistance, anti-flaking and anti-scouring. Castable for carbon calcined rotary kiln is suitable for rotary kiln kiln mouth, pre-tropical zone, calcination zone, cooling machine, feed nozzle and other parts.
Castable for carbon calcined rotary kiln has the advantages of high strength, high wear resistance, anti-flaking and anti-scouring. Castable for carbon calcined rotary kiln is suitable for rotary kiln kiln mouth, pre-tropical zone, calcination zone, cooling machine, feed nozzle and other parts.
|
Items |
CH-JZ70 |
CH-JZ45 |
CH-JZ60 |
|
|
AL2O3 /% ≧ |
70 |
45 |
60 |
|
|
Bulk density (110℃×24h) g/cm3 ≥ |
110℃×24h |
2.6 |
2.4 |
2.4 |
|
Compressive strength /MPa ≥
|
110℃×24h |
40 |
35 |
36 |
|
1000℃×3h |
70 |
65 |
40 |
|
|
1300℃×3h |
80 |
70 |
65 |
|
|
Flexural strength/MPa≥
|
110℃×24h |
10 |
6 |
4 |
|
1000℃×3h |
12 |
8 |
6 |
|
|
1300℃×3h |
16 |
10 |
10 |
|
|
Permanent Linear Change /% ≤ |
0.02 |
0.02 |
0.01 |
|
Castable for carbon calcinator
|
Items |
CH-TLD |
CH-TLQ |
CH-TLZ45 |
CH-TLZ60 |
CH-TLZ70 |
|
|
AL2O3 /% ≧ |
— |
— |
45 |
60 |
70 |
|
|
Bulk density g/cm3 ≥ |
110℃×24h |
2.2 |
2.2 |
2.2 |
2.3 |
2.5 |
|
Compressive strength /MPa ≥
|
110℃×24h |
40 |
50 |
30 |
35 |
40 |
|
1000℃×3h |
40 |
50 |
40 |
40 |
50 |
|
|
Flexural strength/MPa≥
|
110℃×24h |
7 |
8 |
6 |
7 |
10 |
|
1000℃×3h |
7 |
8 |
6 |
6 |
8 |
|
|
Permanent Linear Change /% ≤
|
110℃×24h |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
|
1000℃×3h |
±0.4 |
±0.4 |
±0.4 |
±0.4 |
±0.4 |
|
|
Maximum Service temperature/℃ |
1400 |
1450 |
1400 |
1450 |
1500 |
|
Base on high quality magnesite and graphite as main raw materials, low carbon MgO-C bricks are produced via pressing and low temperature pre-baking and mainly used in slag zone of ladle lined with low carbon or carbon-free refractories for low and ultra-low steel production.
EAF tap-hole filler is developed with magnesite, forsterite and silica as the main materials according to different requirements, and shows the features of easy installation, good sintering, floating resistance, high self-open rate and good safety performance.
Checker Brick is a kind of heat-transfer medium, which is mainly used for middle-upper part of regenerative chamber in hot blast stove for thermal storage in the burning period.
