The high-strength wear-resistant self-flowing castables are made of high-quality bauxite clinker, mullite and fused corundum. The pure calcium aluminate cement, corundum micro-powder and silicon micro-powder are used as binders.
The high-strength wear-resistant self-flowing castables are made of high-quality bauxite clinker, mullite and fused corundum. The pure calcium aluminate cement, corundum micro-powder and silicon micro-powder are used as binders. Such self-flowing castable has the characteristics of high strength, good thermal shock resistance, abrasion resistance, erosion resistance and strong corrosion resistance.Self-flowing castable has good fluidity and convenient construction. Self-flowing refractory castable can be used in CFB boilers and other high temperature furnaces.
Applications of Self-flowing Castable:
The self-flow castable has widely application, especially for blast furnace iron runner, department between stave cooler and blast furnace shell.
Advantages of Self-flowing Castable:
• Environment friendly
• No need vibration and easy to construct to save labor time
• Reasonable raw material and size to make sure good fluidity
• High strength and high refractoriness
|
Items |
CH-zlj75 |
CH-zlj80 |
|
|
AL2O3 % ≥ |
75 |
80 |
|
|
SiO2 % ≤ |
20 |
16 |
|
|
Bulk density g/cm3 ≥ |
2.6 |
2.7 |
|
|
Flexural strength/MPa ≥
|
110℃×24h |
7.0 |
8.0 |
|
1100℃×3h |
11 |
12 |
|
|
Compressive strength/ MPa ≥
|
110℃×24h |
60 |
70 |
|
1100℃×3h |
70 |
85 |
|
|
Normal temperature wear/ cm3≤ |
8 |
9 |
|
|
Refractoriness /℃ ≥ |
1790 |
1790 |
|
|
Thermal shock stability (900℃ ,water-cooling) / times≥ |
20 |
20 |
|
|
PLC (1000℃×3h) / % ≤ |
-0.25 |
-0.25 |
|
|
The self flow value /mm ≥ |
200 |
200 |
|
CH-WS series ladle and tundish well block is made of high purity, high density, high strength raw materials and designed by MAS matrix optimization system , which has the advantages of stable structure, anti-erosion, anti-erosion, good thermal shock stability and long service life.
Lightweight thermal insulating castable is formulated with different types of lightweight aggregates, powders, binders and expansion agents. lightweight castable refractory is a good new type of refractory insulation materials and energy-saving materials.
According to customers' needs, CH Refractories can provide ordinary, quick exchangeable and gas purging upper nozzles. The bowl part of the tundish nozzle is available with Al2O3-C, MgO-C and spinel-C based and the main body is Al2O3-C based.
If you need our products please write down any questions, we will reply as soon as possible.
